Ajax DoorProtect Plus helps to protect doors and unclosed windows across several floors of a house or office. Detects opening, tilt, and impacts.
Maximum performance
- Works up to 1,000 meters from Ajax Hub in open space or across several floors of a business center
- Detects inclination angle relative to the ground
- Built-in accelerometer reacts to vibration and impacts
- Allows for connection to a third-party detector
Protection from intruders and failure
- Uses authentication to protect against fraud
- Tamper-resistant body
- Response from detectors can be checked every 12-300 seconds (adjustable)
- Jamming detection, frequency-hopping
- Uses an encrypted connection
Smooth operation
- Uses British-made reed switches that can be toggled more than 1,000,000 times without failure
- Two-way communication with Ajax Hub allows for periodic testing and customization
- Saves energy by regulating power consumption based on the distance from Ajax Hub
- Has a battery life of up to 5 years when pinging once per minute
Simple professional-level installation
- No need to disassemble the body when installing using SmartBracket mounts
- Uses powerful magnets that can be installed up to 2 cm from the main unit
- The quality of the connection and detection area can be tested remotely
- Connects to Ajax Hub with a single click
Engineering masterpiece
- Its compact size and powerful magnet make Ajax DoorProtect Plus the ideal detector to protect all types of doors and windows
Tech specs
-
Detector type:
Wireless
-
Mounting:
Surface-mounted
-
Detecting elements:
Reed switch, accelerometer
-
Distance to magnet:
Up to 1 cm (0.4 in) (small magnet), up to 2 cm (0.8 in) (big magnet)
-
Use:
Indoor
-
Compatibility:
Works only with Ajax Hub
-
Additional input to plug in the wire detectors:
Available
-
Tamper protection:
Available
-
Radio signal power:
20 mW
-
Communication protocol:
Jeweller (868.0−868.6 MHz)
-
Maximum distance between detector and central unit:
Up to 1,000 m (6562 ft) (in open area)
-
Power supply:
CR123A battery
-
Power supply voltage:
3 V
-
Battery life:
Up to 5 years
-
Operating temperature range:
From 0°С (+32°F) to +50°С (+122°F)
-
Operating humidity:
Up to 80%
-
Dimensions:
20х90 mm (0.78x3.54 in)
