Detects broken glass using an electret microphone, which registers the sound of impact against the glass and of the glass falling.
Features
Two-factor detection of broken glass prevents false alarms caused by thunder, dogs barking and noise from passing trucks.
Installation and set up
Ready to operate straight out the box: the battery is already installed, therefore there is no need to disassemble the detector. With one click, it can be connected to the hub in the mobile application. It can be mounted on the SmartBracket in just a few minutes.
Classification
Surface sound radio channel security detector
Alarm signal delivery time
Power supply
Battery: CR123A battery
Power supply voltage: 3 V
Battery life — up to 7 years
Jeweller radio technology
Communication range with central unit — up to 1,000 m in an open space
Two-way communication between devices
Operating frequencies — 868.0-868.6 MHz
Self-adjusting RF output power — up to 20 mW
Block encryption based on AES algorithm
Detector polling period — 12−300 s
Operating temperature range
Anti-sabotage
Protection against fraud
Jamming detection
Tamper-resistant
Remote setting and testing
Dimensions
Diameter: 20 mm
Height: 90 mm
Certification
DSTU EN 50131, Conforms to the requirements of the technical regulations governing radio equipment
Warranty
Replacement and repair within 24 months of the date of sale. Batteries are not covered under warranty.
Complete set
GlassProtect glass break detector
CR123A battery (pre-installed)
External contact
Installation set
User’s guide
