Wireless battery-powered control panel. Supports photo verification. Connectable via two SIM cards (2G/3G/LTE)
Off-grid security made simple
Hub BP Jeweller is an innovative security control panel designed to secure properties without a constant power supply. It's ideal for protecting vacant houses, construction sites, and temporarily unused offices. Unlike other control panels, Hub BP is powered by internal and external batteries, ensuring long-term autonomous operation. Hub supports event photo verification and features dual SIM connectivity, guaranteeing reliable communication. Thanks to its battery power saver feature, the device optimizes battery usage, providing continuous protection for extended periods.
Impressive autonomy for challenging locations
Hub BP Jeweller operates on internal and external batteries or alternative supplies like solar panels, ensuring exceptional autonomy. This feature makes it ideal for sites where it is impossible to install devices powered by the mains. With its battery power saver feature, the hub can function for months, reducing the need for frequent maintenance visits. This innovation protects remote or off-grid locations, expanding installation possibilities for security professionals.
Ajax devices
up to 100
Specifically, up to 10 sirens or keypads with a built-in siren and up to 5 range extenders.
Ajax NVRs
up to 36
Ajax cameras
up to 224 via Ajax NVRs and up to 492 standalone
Third-party IP cameras
up to 10 when using RTSP via SDK
up to 224 when using ONVIF via Ajax NVRs
Users
up to 50
Any number of admin users within the hub limit.
PRO accounts for installers.
PRO accounts for installation and monitoring companies.
Access management for users.
Automation scenarios
up to 32
By alarm.
By schedule.
By arming/disarming.
By temperature, humidity, CO2concentration.
By pressing Button.
By touching LightSwitch.
Security groups
up to 9
Rooms
up to 50
Event log
up to 1,000 events
Events are saved on the non-volatile onboard flash memory.
Wireless communication
Jeweller communication technology
Proprietary wireless communication technology to transmit commands, alarms, and events.
Key features:
Two-way communication.
Advanced anti-sabotage.
Block encryption featuring a dynamic key.
Instant notifications.
Remote control and configuration in Ajax apps.
Maximum effective radiated power (ERP)
up to 25 mW
Automatic power control to reduce power consumption and radio interference.
Radio signal modulation
GFSK
Radio communication range
up to 2,000 m
Between a hub and connected devices (in an open space). The maximum range depends on the connected device.
Polling interval
from 12 s to 300 s
Adjusted by a PRO or user with admin rights in Ajax apps.
Encrypted communication
All stored and transmitted data are protected by block encryption featuring a dynamic key.
Frequency hopping
To prevent radio interference and jamming.
Wings communication technology
Proprietary wireless communication technology to transmit photos.
Key features:
Two-way communication.
Advanced anti-sabotage.
Block encryption featuring a dynamic key.
Data packages reload in case of transmission errors.
Photo delivery check.
Maximum effective radiated power (ERP)
up to 25 mW
Automatic power control to reduce power consumption and radio interference.
Radio communication range
up to 2,000 m
Between a hub and connected devices (in an open space). The maximum range depends on the connected device.
Encrypted communication
All stored and transmitted data are protected by block encryption featuring a dynamic key.
Frequency hopping
To prevent radio interference and jamming.
Recommendations
Hub BP Jeweller is designed for indoor use only.
Cellular
2 × micro SIM slot
Cellular bands
2G
GSM900/DCS1800 (B3/B8)
3G
WCDMA 850/900/2100 (B1/B5/B8)
4G (LTE)
FDD B1/B3/B5/B7/B8/B20
Automatic switching between communication channels
between SIM cards — up to 4 minutes
Communication channels prioritization
1. Micro SIM slot 1
2. Micro SIM slot 2
Auto APN
TheAPN auto selectfeature allows setting access point automatically based on the installed SIM card.
