AJAX

Ajax WallSwitch

Ajax WallSwitch

Free Shiping

Regular price $41.95 USD
Regular price $54.95 USD Sale price $41.95 USD
Sale Sold out
Shipping calculated at checkout.

Ajax WallSwitch Smart Home Security Switches Domestic Appliances ON | OFF


The radio channel controller allows to control domestic appliances remotely. It is used to switch on/off irons, garage gates, water heaters and heat-insulated floors.

With one click in the mobile application, the device switches domestic appliances on and off
The device switches off automatically during overcurrent, voltage surge and overheating
Information on energy consumption is available in the mobile application

Principle of operation

The device controls the electric power supply by means of relay, which closes and opens the power supply network.

Features

Operates in 110 V and 220 V mains. The meter shows the power consumption in real time.

Installation and set up

It is installed into a recessed wall plate and connected to the internal power supply network.

Tech specs

Classification

Radio channel relay unit

Device type

Wireless

Installation method

Into wall plate

Compatibility

Operates only with Hub and Hub Plus

Actuating element

Relay

Voltage protection

For 230 V mains: max — 264 В, min — 161 В
For 110 V mains: max — 126 В, min — 77 В

Relay service life

200,000 switch-ons

Maximum load current

13 A

Maximum current protection

Yes (13 A)

Maximum temperature protection

>65°C in the wall plate

Permissible power

Resistive load at 230 V — up to 3 kW
Resistive load at 110 V — up to 1.5 kW

Electric power meter function

Available

Energy consumption parameter check

Current, voltage, power consumption

Alarm signal delivery time

0.15 s

Power supply

110−230 V±10% 50/60 Hz

Jeweller radio technology

Communication range with central unit — up to 1,000 m in an open space
Two-way communication between devices
Operating frequencies — 868.0-868.6 MHz
Self-adjusting RF output power — up to 25 mW
Block encryption based on AES algorithm
Detector scanning period — 12−300 s

Operating temperature range

0°С to +64°С

Permissible humidity

Up to 75%

Anti-sabotage

Protection against fraud
Jamming detection

Protection class of body

IP20

Remote setting and testing

+

Dimensions

38х25х18 mm

Weight

30 g

Certification

Conforms to the requirements of the technical regulations governing radio equipment

Complete set

WallSwitch
Installation set
User’s guide
